Logitech Spot Presence and Environmental Sensor

Dimensions

Technical Specifications

System Requirements

• Compatibility: Requires Bluetooth connection to Logitech host CollabOS device (see product support manual for more details: sync.logitech.com/hub/logitech-spot) or LoRaWAN connection to Kerlink iFemtocell Wirnet Gateway Hub
• Certifications: For the latest information on certification and compatibility visit sync.logitech.com/hub/logitech-spot

Electrical & Environmental

• Battery type: 1 x Lithium Thionyl Chloride D-Size
• Battery life: Up to 4 years in optimal conditions
• Power: USB-C 5V, 0.5 A (cable not included)
• See here for more battery life details: sync.logitech.com/hub/logitech-spot
• Operating temperature: 0 to 40°C
• Operating humidity: 10 to 90%, non-condensing
• Storage temperature: -40 to 70°C
• Storage humidity: 10 to 90% RH, non-condensing

Connectivity

• Logitech host devices: Select CollabOS devices. See here for more details: sync.logitech.com/hub/logitech-spot
• Connection Type: Bluetooth, LoRaWAN

Sensors

• Presence Sensor: Sensor technology: mmWave radar technology, Mounting position: wall, Sensing distance: up to 8 m, Sensing field of view: 120° horizontal / 100° vertical
• Particulate Matter Sensor: Sensor technology: Laser particle counter (Light scattering), Mass concentration range: 0 to 1,000 μg/m³, Output resolution: 1 μg/m³, PM2.5 Accuracy: At 1 to 100 µg/m³, ± 5 µg/m³ ± 5%; At 100 to 1000 µg/m³, ± 10%, PM10 Accuracy: At 1 to 100 µg/m³, ± 25 µg/m³; At 100 to 1000 µg/m³, ± 25% [Note: Accuracy depends on sensor deployment mode.]
• CO₂ Sensor: Sensor technology: Non-dispersive Infrared (NDIR), Mass concentration range: 400 to 10000 ppm, Output resolution: 1 ppm, Accuracy: At 400 to 5000 ppm, ± 3%; at 5000 to 10000 ppm, ± 10%
• Pressure Sensor: Sensor technology: MEMS, Pressure range: 30 to 125 kPa, Output resolution: 1.45 Pa, Accuracy: ± 77 Pa at 30 to 110 kPa
• TVOC Sensor: Sensor technology: Metal oxide chemiresistor, Range: 1 - 6000 µg/m³, Resolution: 1 µg/m³, Measurements provided: tVOC index and tVOC absolute values, Accuracy: At 1 to 1000 µg/m³, ± 20 µg/m³ ± 15%; At 1000 to 2000 µg/m³, ± 20 µg/m³ ± 20%
• Temperature Sensor: Sensor technology: Metal oxide semiconductor, Temperature range: -40 to 125°C, Resolution: 0.1°C, Accuracy: ± 0.4°C at -10 to 80°C
• Humidity Sensor: Sensor technology: Metal oxide semiconductor, Relative humidity range: 0 to 100% RH, Output resolution: 0.1 % RH, Accuracy: ± 3 % RH at 10 to 90% RH

Sustainability

• Responsible Packaging: The paper packaging of Logitech Spot comes from FSC™-certified forests and other controlled sources.
• Recycled Plastics: The plastic parts in Logitech Spot include 33% certified post-consumer recycled plastic to give a next life to plastic from old consumer electronics and help reduce our carbon footprint. *Excludes plastics in printed wiring assembly, cables, module, FFC, and packaging.
