Logitech Rally Camera Streamline Kit

Dimensions

• Rally Camera
  • Height: 7.19 in (182.5 mm)
  • Width: 5.98 in (152 mm)
  • Depth: 5.98 in (152 mm)
  • Weight: 3.35 lb (1.52 kg)
• Camera Side Base for Rally Camera Extension Kit
  • Diameter: 6.04 in (153.3 mm)
  • Height: 1.24 in (31.5 mm)
  • Weight: 9.02 oz (255.8 g)
• Control Side Box for Rally Camera Extension Kit
  • Height: 5.30 in (134.7 mm)
  • Width: 4.61 in (117.2 mm)
  • Depth: 0.90 in (22.8 mm)
  • Weight: 4.85 oz (137.5 g)
• Twist-to-Lock Mount Plate for Rally Camera Extension Kit
  • Diameter: 5.42 in (137.6 mm)
  • Height: 0.73 in (18.6 mm)
  • Weight: 1.49 oz (42.1 g)
• Wall Mount for Rally Camera Extension Kit
  • Length: 6.5 in (165 mm)
  • Width: 5.31 in (135 mm)
  • Height: 5.83 in (148 mm)
  • Weight: 22.93 oz (650 g)
    ^?
• 1.5in NPT Adapter for Rally Camera Extension Kit
  • Diameter: 4.63 in (117.5 mm)
  • Height: 0.60 in (15.2 mm)
  • Weight: 7.05 oz (200 g)
• Rally Camera Preset Button
  • Diameter: 2.83 in (71.9 mm)
  • Height: 0.60 in (15.2 mm)
  • Wall Mount Diameter: 2.65 in (67.2 mm)
  • Wall Mount Height: 0.23 in (5.80 mm)
  • Weight: 1.52 oz (43.2 g)
    ^?
• Fully Assembled Rally Camera with Camera Side Base and Wall Mount
  • Length: 6.97 in (177 mm)
  • Width: 5.83 in (148 mm)
  • Height: 8.27 in (210 mm)
  • Weight: 5.44 lb (2.47 kg)
    ^?
• Fully Assembled Rally Camera with Camera Side Base and 1.5in NPT Adapter
  • Length: 5.83 in (148 mm)
  • Width: 5.83 in (148 mm)
  • Height: 8.66 in (220 mm)
  • Weight: 4.45 lb (2.02 kg)

Technical Specifications

• Ports and Interfaces
  • Control Side Box: Front
    • Reboot button
    • LED status indicator
  • Control Side Box: Rear
    • USB-C (from Control Side Box to user device)
    • RJ45 to Camera Side Base
    • DC Power Connection
    • Built-in cable retention
    • Mounting slots
  • Camera Side Base
    • Integrated USB-C cable (from Camera Side Base to Rally Camera)
    • RJ45 to Control Side Box
  • Preset Button
    • Bluetooth Low Energy
    • Switch mechanism to lock/unlock preset and BT pairing functionality
• Mounting
  • Control Side Box
    • Mounting slots: 2 through-slots for mounting directly to the wall, table or shelf
  • Camera Side Base
    • VESA: 2.95 x 2.95in (75x 75 mm)
    • Tripod: ⅝-27 and ¼-20
    • Twist-to-lock: for mounting directly to twist-to-lock mounting plate
  • Preset Button Mounting Plate
    • Mounting Holes: 2 through-holes for mounting directly to the wall or table (mounting hardware included)
    • Adhesive Strip Placement: 2 designated areas for placement of small adhesive strips 46 x 16 x 16 mm (adhesive strips not included)
  • Wall Mount for Rally Camera Extension Kit
    • Mount directly to a 2-gang box or standard wall surface such as drywall (mounting hardware included)
  • 1.5in NPT Adapter for Rally Camera Extension Kit
    • VESA: 2.95 x 2.95in (75x 75 mm) (mounting hardware included)
• Power and Cables
  • Rally Camera Extension Kit
    • Power Supply Operating Voltage/Power: 100-240V, 48V, 1.0A
    • Power Supply Dimensions: 68.9 x 33.9 x 71.3 mm
    • DC Cable: 5 ft (1.5 m)
    • USB-C to USB-C 2.1 Cable: 6.5 ft (2 m)
    • USB-C to USB-A 2.1 Adapter: 1.46 in (37 mm)
  • Preset Button
    • 2x CR2032 batteries
  • Camera
    • HD imaging system supports
    • Smooth motorized pan, tilt and zoom
    • Field of View
• Remote Control
  • RF remote control (line of sight not required)
  • CR2032 battery (included)
• Autofocus
• Kensington security slot

System Requirements

• Windows 10 and higher
• macOS: two most recent versions
• USB 2.0 compatible devices
• Category cable support: Cat5e or better with cable diameter up to 7.4mm. Performance and length supported will vary by cable up to 100m.
